1. Paper six rolls at the same time 2. Core paper预热 3. Core paper glue line 3. Core paper composite drying 4. Crosscutting machine 5. Automatic collection of paper core
1. Three years of research and development and 20,000 hours of production evaluation in their own factory, stable and reliable quality performance.
2. Using the latest technology and production process, it is the most advanced cellular equipment with the highest production capacity and the lowest loss in China. The maximum cutting speed can reach 700 knives/min.
3. Full computer control. Improve equipment control details high automation, more convenient operation.
4. Dust-free, tasteless, pollution-free, compound (meet) environmental requirements.
| Machine Model | HX-2000-700J |
| Core Paper Effective Width | 1200mm-2000mm |
| Side Length Of Honeycomb | Can be customized according to customer needs |
| Transverse Cutting Speed | 700 times /min(thickness 5mm, paper core weight 100g) |
| Core Paper Thickness | 5-60mm |
| Production speed | 100m/min |
| Heating Method | Steam heating |
| Equipment Power | 30KW |
| Overall Dimensions | 30500mm long x4500mm wide x3000mm high |
| Equipment Weight | Approx. 42T |
